Doxmall RGB 4Pcs 9005+9006 Combo LED Headlight Bulb Kit App Control Fog Lamps for Chevy Silverado GMC Sierra 1500 2500 00-06

Doxmall RGB 4Pcs 9005+9006 Combo LED Headlight Bulb Kit App Control Fog Lamps for Chevy Silverado GMC Sierra 1500 2500 00-06


SKU: RGB-9005+9006 Category:

Specifications :

Name : RGB LED Headlight Bulb
Voltage: DC 9-36V
Power: 40W (20W/Bulb)
Luminous Flux: 6000Lm (3000LM/Bulb)
Lifespan: >30,000 Hours
Waterproof Grade: IP68
Application: Car Headlight/ Foglight
Cooling: Fan Cooling
Control : By Smart Phone APP through Bluetooth.
Warranty : 1 Year


  • Introduction: Name: RGB seven-color remote control headlights;With Canbus : Fit for all universal car by this canbus . Called error dismiss- Without any Lighting error code in you car , start engine and ligting directly.–Cooling : By Fan to keep longer Lifesapan of this Hedlight bulb or Fog light.
  • Working temperature: -40 ° C + 85 ° C working temperature make your lights work normally in a harsh condition.
  • Change color in order to suitable weather or your idea : car headlights , fog light. If you wanna use it as a fog light , you can change color by yourself and won’t effect your usual driving .
  • As Headlight , you will have nice view at foggy ,snowy, raining or sand weather. Change it into yellow , you will get well view in those unnormal weather.
  • The headlight color is white, and the colorful light can be used as fog light. Be sure to download the APP that controls the light before using the Bluetooth remote control.

Package Included:

2Pcs 9005+2Pcs 9006 RGB LED Headlight Bulb


Step 1

  • Determining how to access the headlight bulb is easily the most challenging part of the job. While it seems like you should be able to just pop the bulb out, often times you have to remove other parts just to get to the bulb.
  • On most vehicles, you reach the headlight bulb through the engine compartment. Open the hood and look for the headlight sitting in a bulb holder. Also check your owner’s manual for information on the best way to get to the headlight bulb and what parts you might have to remove to reach it.

Step 2

  • Assess how to remove the old bulb. On some vehicles, the bulb is secured in the headlight assembly by a wire assembly while other cars have the bulb positioned directed into the headlight assembly. Once you know how the bulb is held in the housing, you’ll know how to remove it.
  • At this point, you’ll also be able to determine what tools you’ll need to complete the job. Many headlight bulbs can be removed without tools, but some do required the use of a flathead or Phillips screwdriver.
  • If there are power wires connected to the back of the bulb, remove them. There might also be a dust cover that you need to remove from the back of the headlight. There could also be a clip(s) that holds the bulb in place.

Step 3

  • Remove the bulb by holding the bulb housing and pulling it out. On some bulbs, you might have to use a twisting motion to remove it. Use a gentle touch when doing this so you don’t risk breaking the bulb.

Step 4

  • Before installing the new bulb, clean it with an alcohol wipe or by using rubbing alcohol and a lint-free cloth.
  • Grasping the new bulb by the housing, line it up with the open socket and insert it. Avoid touching the bulb, the oil from your skin can leave a hot spot that may cause it to burn out faster. You may consider wearing gloves to avoid this issue.
  • Reverse the process you used to remove the old bulb. Attach any wires or clips and replace the dust cover on if necessary. Put the headlight housing back in the frame. Replace any additional parts that you had to remove to gain access to the headlight bulb.

Step 5

  • Start up your vehicle and turn on the headlights to ensure that the new headlight is working properly. Also take time to check the aim of the headlights. If your lights aren’t aligned correctly, they may not be focused on the road – where you need the light to shine brightly. If they seem to be out of alignment, consult your owner’s manual for tips on correcting it.


1.Test all components before mounting: As shown below, plug ALL light units together and connect them to the controller and the switch wiring harness. Connect the RED battery terminal to the POSITIVE pole of 12V DC battery. Connect the BLACK battery terminal to the NEGATIVE pole. Turn on the switch and push the touch button to test all lights. The RGB LEDs on both sides of each bulb should light up. If the lights show any defects, please contact us and we will be happy to replace them for you.

2.Install the bulbs: Remove the existing bulbs from the headlights. Using the supplied collars, install the RGB bulbs into the headlights. Following the diagram below, plug the bulbs into the drivers and the drivers into the stock headlight plugs. Power headlights on to ensure proper install. Connect the other plug on each bulb to the Bluetooth controller.
WARNING: Do not force the plugs together! If they don’t snap together, verify that all the pins line up. If a pin is out of place, it must be straightened in order for the plugs to snap together.

3.(Optional) Connect sensor wire: If desired, connect the red sensor wire to desired 12V source.

4. Secure all wires and connectors: Use provided zip ties to neatly mount and hide any loose wires. Use provided double sided tape to hold male and female plugs together and to mount the LED drivers. Make sure wires are not touching anything hot or located on moving parts. Locate the ON/OFF switch and controller in a convenient location.
5. Connect to 12V DC power: Firmly connect the wire terminals to the positive and negative poles of the battery. Power on, download the App, and enjoy!

Fitments:It fits most cars with H1 headlights, such as:
(Including but not limited to the following models)
2010-2011 Dodge Journey
2013-2016 Dodge Journey
2010 Dodge Charger
2011-2015 Nissan Armada
2010-2012 Chevrolet colorado
2014 Chevrolet colorado
2010-2013 Honda Civic
2010 Honda Odyssey
2011-2012 Toyota Corolla
2011 Toyota Matrix
2013 Toyota Matrix
2011-2012 Toyota RAV4
2016 Toyota RAV4
2011 Acura
2010-2011 GMC Canyon
2010 Chrysler 300
2016-2017 Chrysler 200
2010 Jeep Grand Cherokee
2016-2017 Jeep Compass
2017 Ram 3500
2016 Ram 1500
2016-2017 Dodge Challenger
2016-2017 Ford Edge
2017 Ford Escape
2016-2017 Ford Expedition
2016-2017 Ford F-150
2016-2017 GMC Acadia
2017 GMC Sierra 1500
2016-2017 GMC Sierra 3500 HD
2016-2017 GMC Canyon
2017 Honda Pilot
2016 Mazda 3
2016 Mazda 6

Install Caution:

  1. As a safety precaution, make sure that the car has had time to cool down properly before starting the installation process.
  2. Put the vehicle into park or make sure it is securely in gear.
  3. Make sure to have the ignition turned off and the keys removed.
  4. Be careful to avoid burns, especially when turning on or off the vehicles lighting.
  5. Be careful to avoid crushing or cutting the bulbs. Also make sure to not touch the bulbs with your fingers, as this will cause blotting.
  6. Fully examine the connection of the contact points, ports and the wires as faulty connections can cause lighting problems.
  7. Make certain that the end of the bulb does not come in contact with the interior light shield of the headlight when adjusting the bulb

Purchase Notes:

* Please check the Correct bulb size of your vehicle before ordering!
* If you are unsure your bulb type, please do remember send message to tell us your car make, model, year and other information which is helpful to check bulb type.
* Professional installation is highly recommended if you have any difficult in installation..


Additional Information

Weight 1.3 kg
Dimensions 21 × 16 × 6.3 cm
